2-piece CR mounting
CR-Controlled Rebound mounting
A range of mounting designed for high load capacity and low installation height.The high loading for a given size is achieved by utilizing the rubber to best advantage in shear and compression.
•  Off-highway engines and Cabs
Features
With washer it is a compact fail-safe design easy to fit with a single bolt.
•  Integral bonded steel flange prevents rubber wear at interface with bracket.
•  No radius or chamfer required for installation hole.
•  2-piece design gives excellent isolation performance and rebound control during shock loading of the vehicle.
Type
Part no.
Dimension (mm)
Bolt Size
Max. Bolt Torque Nm
Max. Load kg
Washer Part no.
D
D1
d
H
H1
E
C ±0,2
17-2190-45
20-01110-01
65
37.8
16
23.3
15.1
12
37.9
M16
170
75
20-01495-01
17-2190-60
20-01111-01
65
37.8
16
23.3
15.1
12
37.9
M16
170
100
20-01495-01
17-2178-45
20-02506-01
94
55.5
16
28
19
20
56.0
M16
250
115
20-01494-01
17-2178-60
10-03729-01
94
55.5
16
28
19
20
56.0
M16
250
210
20-01494-01
17-1984-45
10-03727-01
100
60
22
38
25.8
25
60.5
M22
500
260
20-01493-01
17-1984-60
10-03728-01
100
60
22
38
25.8
25
60.5
M22
500
400
20-01493-01
17-1931-45
10-00622-01
118
75.5
20
38.3
26.4
25
76.0
M20
500
225
20-01493-01
17-1931-60
10-00623-01
118
75.5
20
38.3
26.4
25
76.0
M20
500
430
20-01493-01
11-1029-45
10-03722-01
115
63
27
45
33.5
25
64.0
M24
700
550
20-00534-01
11-1029-60
10-00793-01
115
63
27
45
33.5
25
64.0
M24
700
900
20-00534-01
