| Features |
RAEM is a universal mounting for applications demanding maximum isolation. It is a further development of RA, where EM stands for “extra soft”. Suitable for both light and heavy machines.
|
For normal speeds of approx. 1500 rpm the RAEM type provides a degree of isolation of 85-95%, and gives good isolation with low frequency machines.
|
| Its unique construction and the latest production methods make Novibra type RAEM a high performance mounting having a number of advantages: |
| • Rubber features are utilised effectively combining compression and shear. |
| • Wide load rating options, 10-3400 kg. |
• Corrosion protected to cope with arduous environments on land or marine applications (Fe/Zn8C as per ISO 2081). |
• Fitted as standard with an integral fail-safe design with resilient stop, making RAEM ideal for use on mobile or marine applications. The RAEM mounts can accomodate occasional shock loads to 5 g reference to the weight in hardness 60° IRH. The mount will withstand shock loads up to 2 g without plastic deformation. |
| • Clear and durable product marking so that mountings can be identifi ed even after several years in operation. |
| • Domed shape cover to protect against oil contamination. |
